` Undo Violet Group

CS 151 - Undo Violet

Craig Huff, Qi Liu, Yuliang Pan, Hengyi Shi

Cover page image

Git Repo

Project Design




  • Command Style
    •


    public interface ICommand{
    boolean Execute();
    void UndoExecute();}



  • CommandManager
    •

  • AddCommand
    •

  • DeleteCommand
    •


    Project Implementation







    This is the basis for the Add and Delete Commands.

     // @Override
    public boolean Execute()
    {
        if (isNode)
        {
            graph.add(node, point);

        }
        else if (!isNode)
        {
            graph.connect(edge, mouseDownPoint, point);
        }

        return true;
    }

    // @Override
    public void UndoExecute()
    {
        if (isNode)
        {
            graph.removeNode(node);
        }
        else if (!isNode)
        {
            graph.removeEdge(edge);
        }

    }

      This is CommandManager Class.

      private Stack commandUndoStack = new Stack();
    private Stack commandRedoStack = new Stack();

    public void ExecuteCommand(ICommand cmd)
    {
        cmd.Execute();
        commandUndoStack.push(cmd);
    }

    public void Undo()
    {
        if (!commandUndoStack.empty())
        {
            ICommand cmd = commandUndoStack.pop();
            cmd.UndoExecute();
            commandRedoStack.push(cmd);

        }
    }

    public void Redo()
    {
        if (!commandRedoStack.empty())
        {
            ICommand cmd = commandRedoStack.pop();
            cmd.Execute();
            commandUndoStack.push(cmd);
        }
    }



    Collaboration








  • Facebook Messenger
    •

  • Git Issues
    •

  • Room for improvement
    •
